Tsim thiab tsim kho lub teeb Steel Structure Enclosure Systems

Nyob rau hauv xyoo tas los no, lub teeb steel qauv tau siv dav hauvSteel Structure Warehouses, Me Steel Structure Exhibition Halls ,Thawv Tsevthiab cov tsev ua haujlwm vim nws tsis siv steel, luv tsim thiab installation lub sij hawm thiab siab industrialized ntau lawm degree. Qhov no tau txhawb txoj kev loj hlob ntawm steel qauv enclosure system los ntawm unitary mus rau diversified, uas nyob rau hauv lem tau ua rau cov kev hloov ntawm tshiab tsim tswv yim thiab tshiab kev tsim kho txoj kev.

Lub kaw lus ntawm lub teeb yuag steel qauv feem ntau suav nrog phab ntsa, lub ru tsev system, teeb pom kev zoo siv, ntug wrapping thiab flashing, gutter thiab kub preservation paj rwb, thiab lwm yam. Lub kaw lus kaw lus yog ib qho tseem ceeb tshaj plaws ntawm lub teeb yuag steel qauv, uas txiav txim siab qhov zoo nkauj ntawm lub tsev, kev tiv thaiv dej thiab kev txuag hluav taws xob ntawm lub tsev.

1 、 Tsim thiab Kev Tsim Kho Vaj Tsev thiab Phab Ntsa Systems

1.1 Kev faib tawm ntawm cov xim phaj enclosure system

Xim phaj enclosure tau muab faib ua: ib txheej phaj, EPS sandwich vaj huam sib luag, BHP xim steel phaj, GRC phab ntsa vaj huam sib luag, polyurethane sandwich vaj huam sib luag, iav ntaub plaub rau ntawm qhov chaw sib xyaw sandwich vaj huam sib luag, pob zeb wool sandwich vaj huam sib luag raws li muaj pes tsawg leeg.

Raws li kev tsim kho hom yog muab faib ua: ua tiav cov vaj huam sib luag, qhov chaw sib xyaw vaj huam sib luag. Field composite board kev twb kev txuas hom yog muab faib ua: lap board, tom board, tsaus buckle board.

Raws li cov khoom siv tau muab faib ua: galvanized xim steel phaj, titanium phaj, aluminium zinc xim steel phaj, aluminium alloy phaj siab phaj, stainless hlau phaj siab phaj, tooj liab phaj.

1.2 Kev txiav txim siab tsim

Field composite phaj vim nws cov nqi ua haujlwm qis thiab kev tsim kho tshuab yog qhov paub tab, yog li hauv lub teeb steel qauv yog dav siv. Ru tsev xim phaj nrog 0.376t thiab 0.5t tuab galvanized ci xim phaj.

ru tsev txoj kab nqes cuam tshuam rau qhov tso dej los nag rau ntawm lub ru tsev, hauv kev tsim lub ru tsev txoj kab nqes yuav tsum tau noj 1/8-1/20, nyob rau hauv lub cheeb tsam ntawm cov dej nag ntau yuav tsum tau coj tus nqi loj (saib CECS102:98), ntxiv rau. mus rau lub ru tsev txoj kab nqes thiab kev siv lub ru tsev board hom uas muaj feem xyuam rau kev siv dav dav ntawm cov ntsia hlau phaj txoj kab nqes yuav tsum loj dua, cov kev cai zais me me.

Loj-span steel qauv ru tsev vaj huam sib luag yuav tsum tau siv zais buckle hom xim hlau phaj. Nyob rau hauv ib tug loj tus naj npawb ntawm engineering daim ntaub ntawv, zais fastening hom xim hlau phaj qhia tau hais tias cov nram qab no zoo: (1) Tsis txhob kub sib txawv los ntawm ntau deformation ntawm lub ru tsev vaj huam sib luag, self-tapping screws raug txiav tawm. (2) Nyob rau hauv lub rainy cheeb tsam, typhoon cheeb tsam nthuav nws tus kheej tapping screws nyob rau hauv qhov kub thiab txias deformation, cua load vibration, roj hmab lev aging, nws yog heev yooj yim mus ua corrosion thiab dej to, siv concealed fastening hom xim hlau phaj tau zam dhau qhov xwm txheej saum toj no. Rau ib txoj kab nqes hav ntev dua 60 meters ntawm lub ru tsev yuav tsum tau ua tiav rau hauv ob lub rooj tsavxwm, tsim cov pob qij txha ntawm cov laug cam, nrog rau TETA npog daim ntawv txuas, TETA daim ntawv npog tuaj yeem zawv zawg nrog cov xim phaj ib leeg, tuaj yeem daws qhov teeb meem ntawm qhov kub thiab txias deformation.

1.3 Kev ceev faj txog kev tsim kho

Hauv kev tsim kho, rau qhov loj ntawm lub ru tsev, cov xim phaj xav tau tag nrho daim ntawv molding phaj, vim hais tias lub crane nqa phaj yog ib qho yooj yim ua rau deformation ntawm lub phaj, yog li lub installation feem ntau tsis siv lub crane, ntau xim rau. nqa lub winch semi-slope lifting.

2 、 Teeb pom kev zoo sawb hlaws tsim thiab kev tsim kho

Lub teeb pom kev zoo raws li cov khoom siv tau muab faib ua iav fiber ntau reinforced polyester lub teeb lub rooj tsavxwm, polycarbonate ua los ntawm honeycomb lossis khoom phaj, thiab lwm yam., raws li cov duab tuaj yeem muab faib ua tib lub waveform nrog lub ru tsev vaj huam sib luag ntawm iav fiber reinforced polyester lub teeb board ( hu ua fiberglass fiber reinforced yas lub teeb vuas) thiab lwm yam tiaj tus los yog nkhaus nto ntawm lub teeb board.

Cov teeb pom kev sib txawv muaj ntau txoj kev kho, polycarbonate teeb pom kev zoo panels siv aluminium profile fasteners, waveform teeb pom kev zoo panels siv teeb pom kev zoo vaj huam sib luag bracket thiab self-tapping screws los txuas thiab kho, thiab tom qab ntawd muab cov nplaum nplaum. Txoj hauj lwm ntawm lub teeb-reflecting phaj yog feem ntau teem nyob rau hauv nruab nrab ntawm lub span. Lub teeb pom kev zoo thiab tus kheej tapping screws txuas nrog, yuav tsum muaj lub hau npog. Sunshine phaj kub thiab txias deformation yog loj, yooj yim rau nws tus kheej tapping ntsia hlau txiav, yog li lub hnub ci phaj nyob rau hauv tus kheej-tapping rau tes yuav tsum tau qhib ntawm lub qhov loj. Nyob rau hauv lub installation ntawm lub teeb vaj huam sib luag los xav txog kev nthuav dav thiab kev cog lus ntawm lub teeb vaj huam sib luag.

Lub teeb pom kev zoo hauv 12m lossis tsawg dua yam tsis muaj ceg tawv, ntau dua 12m yuav tsum tau ceg tawv, ceg ntev ntawm 200-400mm, ceg tawv ntawm daim ntawv thov ntawm ob lub sealant, transverse lap tsis tas yuav tsum tau ntug, longitudinal xim phaj phaj nyob ntawm hom phaj, zoo tib yam compression molded steel phaj, feem ntau tsis kuaj cov ntug tsis tseeb, ncaj qha nrog cov xim phaj thiab cov xim phaj nrog tus kheej-tapping rau tes, thiab daim ntawv thov ntawm sealing sealant, tom ntawm lub rooj tsavxwm yuav tsum ua ntug.

Lub teeb pom kev zoo ntawm qhov ntev ntev kev taw qhia lap yuav tsum tau teem rau hauv sandalwood sawb ze ntawm lub ru tsev waterproofing kev kho mob yuav tsum tau siv sealant txheej, sealant nto yog yooj yim rau kev laus; lapse siv ob dej cement nyob rau hauv nruab nrab ntawm ib tug dawb los yog tsis muaj xim sealant.

Teeb pom kev zoo sab nrauv xim phaj phaj: qhib hom ntsia hlau ru tsev vaj huam sib luag lossis tsaus hom buckle ru tsev vaj huam sib luag, lub rooj tsav xwm lub teeb yuav tsum tau tshwj tseg lub rooj tsavxwm zoo dav, nyob rau hauv lub teeb board crest nrog ntev self-tapping screws tsau, coj mus rau hauv tus account lub thermal expansion thiab contraction ntawm Lub teeb lub rooj tsavxwm tsis zoo ib yam, yuav tsum tau siv los ua ntej punched lub teeb lub rooj tsavxwm ua haujlwm (8 hli qhov tsim nyog), tus kheej tapping screws yuav tsum tau muab tso rau hauv qab lub tshuab ntxhua khaub ncaws muaj zog, tiv thaiv lub teeb board thermal expansion thiab contraction ntawm cov ntsia hlau. tom qab tawg.

3, rwb thaiv tsev ntaub

Rwb thaiv tsev paj rwb muaj pob zeb wool, iav fiber ntau thiab lwm yam ntaub ntawv, rwb thaiv tsev paj rwb muaj zoo thermal rwb thaiv tsev zog, kev tsim kho thiab installation yooj yim, lub zog txuag nyhuv yog zoo kawg li, tsis tshua muaj thermal conductivity thiab lwm yam ntxwv. Tam sim no, cov txheej txheem vov tsev ntawm lub tsev steel qauv Rhiav tau txais: (1) steel hlau mesh + aluminium ntawv ci rwb thaiv tsev paj rwb + ib xim phaj; (2) ob chav xim phaj + rwb thaiv tsev paj rwb thiab lwm yam ob txoj kev.

Cov hauv qab no feem ntau yog qhia xaim mesh + aluminium ntawv ci rwb thaiv tsev paj rwb + ib xim phaj ru tsev txoj kev siv.

Stainless hlau hlau los yog galvanized hlau hla rub tawm pob zeb diamond los yog duab plaub, nrog 215 cm ntev nws tus kheej tapping ntsia hlau tsau nyob rau hauv purlin, tso iav ntaub plaub dov xav, txhuas ntawv ci ntsej muag rau sab hauv tsev, perpendicular mus rau lub purlin, nyob rau hauv lub eaves ntawm lub ob sab ntawm ntau sab laug txog 20 cm ntawm dov xav, nrog ob-sided daim kab xev yuav raug kho nyob rau hauv lub sab nrauv guillotine ntawm lub purlin. Siv lub 20 centimeters ntawm veneer tseg rau iav ntaub plaub edging. Ua tib zoo saib xyuas qhov nro ntawm cov iav ntaub plaub dov xav, kev sib dhos, cov pob qij txha nruj ntawm cov yob, qhov ntev xav tau rau lub puab tsaig, lub puab tsaig pob qij txha yuav tsum tau teem caij rau hauv lub purlin. Raws li qhov xav tau ntawm qhov project, txhawm rau zam lub cim ntawm tus choj txias, tuaj yeem txiav txim siab hauv purlin ncoo rigid rwb thaiv tsev cov khoom.

4. Gutters thiab soffits

Eaves tuaj yeem muab faib ua cov dej ntws sab nraud gutter eaves, sab hauv dej gutter eaves thiab free-fall gutter peb daim ntawv raws li cov qauv. Qhov tseem ceeb tshaj plaws tuaj yeem muab rau kev siv lub caij nplooj zeeg dawb thiab sab nraud cov dej ntws tawm eaves daim ntawv. Raws li cov ntaub ntawv cov ntsiab lus muaj stainless hlau gutter, steel phaj gutter, xim phaj gutter. Gutter raws li lub ntsiab ru tsev qhov system, txiav txim siab los nag thiab daus paug, lub tsev ru tsev ib txwm siv ntawm kev ua haujlwm.

Daim duab 2 Exterior Drainage Gutter Eave Practice

Sab nraum lub qhov dej gutter gable vim kev tiv thaiv to, tus nqi qis, hauv qhov project kuj tuaj yeem siv dav. Sab nraum cov kua dej gutter gutter feem ntau yog coj nrog cov xim phaj gutter. Kev tsim cov xim phaj gutter tsis tas yuav txhawb nqa nws cov khoom siv, cov phab ntsa gutter tuaj yeem ncaj qha rau ntawm phab ntsa sab nrauv, teeb tsa ntawm phab ntsa txhawb nqa, hauv cov ru tsev panels ntawm cov khoom sib txuas tau khaws rau ntawm phab ntsa sab nrauv ntawm lub qhov dej. , cov seem ntawm lub gutter sib tshooj sib tshooj, siv cov rivets los txuas thiab sealant sealing. Kev ua haujlwm tuaj yeem siv tau hauv kev xyaum ua hauv daim duab 2.

Daim duab 3 Edging thiab flashing xyaum

5, Ntug thiab Flashing

Edging thiab flashing tsis tsuas yog qhia txog cov kab ntawm lub tsev, cuam tshuam rau qhov zoo nkauj ntawm lub tsev, thaum kev sib txuas ntawm lub tsev mus rau tag nrho, windproof, rainproof, kom lub tsev ruaj khov dua. Saib daim duab 3 kom paub meej.

6. Cov ntsiab lus thiab cov lus xaus

Lub teeb steel qauv tau lug siv nyob rau hauv lub Hoobkas tsev, me me exhibition halls thiab chaw ua hauj lwm cov tsev vim nws tsis tshua muaj steel noj, luv installation thiab tsim lub sij hawm, thiab high degree ntawm industrialized ntau lawm. Nws lub kaw lus kaw feem ntau siv cov xim hlau phaj, kev tshawb fawb sau cov xim hlau phaj tu qhov system tsim thiab kev tsim kho, muab tso rau pem hauv ntej kev lag luam thiab tsim nyog ntawm tus qauv thiab kev tsim kho muaj qhov tseem ceeb ntawm cov tswv yim.

Rau sab pem teb hom phaj phaj, yuav tsum muab qhov tseem ceeb rau kev siv cov buckle tsaus hom xim hlau phaj qauv ua, tuaj yeem zam qhov kub ntawm qhov sib txawv deformation los ntawm tus kheej tapping ntsia hlau yog sheared, tib lub sijhawm tuaj yeem zam hauv qhov chaw los nag. , typhoon cheeb tsam raug tus kheej tapping ntsia hlau nyob rau hauv qhov kub thiab txias deformation, cua load vibration, roj hmab lev aging tshwm sim los ntawm lub phaj corrosion thiab dej to phenomenon.

Lub teeb pom kev zoo tsim thiab kev tsim kho yuav tsum tau them sai sai rau nws cov thermal expansion thiab contraction, teeb pom kev zoo board thiab self-tapping ntsia thawv txuas yuav tsum muaj ib lub hau. Nyob rau tib lub sijhawm, xyuam xim rau nws qhov sib txawv nrog cov xim hlau phaj. Lub teeb pom kev zoo yuav tsum tau ua ua ntej punched (8 hli qhov tsim nyog).

Txhawm rau kom tsis txhob muaj kev sib txuas ntawm tus choj txias, koj tuaj yeem xav txog padding nruj rwb thaiv tsev sib xyaw board ntawm lub purlin.

Nyob rau hauv cheeb tsam sab qaum teb nrog me ntsis los nag thiab qhov project tsis xav tau qib siab ntawm eaves, nws raug nquahu kom siv cov eaves dawb-caij nplooj zeeg. Nws cov dej xau yog qhov zoo, tus nqi qis, hauv qhov project tau dav siv.
